| American Wire Gauge |
23AWG |
| Application/Usage |
Premise Horizontal Cable, Ethernet up to 10GBASE-T, Wi-Fi 6, Wi-Fi 5, Surveillance, HDBaseT, PoE++, PoE+, PoE, Noisy Environments |
| Cable Length |
304m |
| Cable Type |
F/UTP |
| Conductor Count |
8 |
| Conductor Material |
Bare Copper |
| Data Transfer Rate |
10Gbps |
| Diameter |
6.7mm |
| Environmental Certification |
REACH; RoHS Compliant; WEEE |
| Environmentally Friendly |
Yes |
| Features |
100% Shield coverage; 10GBASE-T support; 500MHz Bandwidth; Flamarrest PVC-LS Jacket; Noise reduction in noisy environments; Plenum-rated (CMP); PoE++ compatible (up to 100W); Small diameter (0.265 in); Solid Bare Copper conductors; Supports Wi-Fi 6 and Wi-Fi 5 |
| Indoor/Outdoor |
Indoor |
| Insulation Material |
FEP (Fluorinated Ethylene Propylene) |
| Jacket Material |
PVC (Polyvinyl Chloride) |
| Material |
Bare Copper |
| Maximum Operating Voltage |
300V |
| Number of Conductors |
8 |
| Number of Pairs |
4 |
| Package Type |
Reel/Spool |
| PoE |
Yes |
| Product Line |
10GXW |
| Product Series |
10GXW |
| Product Type |
Cable |
| Shielding |
Yes |
| Solid or Stranded |
Solid |
| Voltage Rating |
300V |
| Weight |
16.78kg |
| Maximum Operating Temperature |
75°C |
| Additional Information |
Electrical values are expected performance based on cable testing and representative performance within a typical system. |
| CE Marking |
Yes |
| Certifications & Standards |
NFPA 262 Plenum (UL 910), FT6, CMP, S-116-732, IEEE 802.3bt Type 1, Type 2, Type 3, Type 4, ANSI/NEMA WC-66, ANSI/TIA-568.2-D Category 6A, ISO/IEC 11801-1, IEC 61156-5, REACH, EU Directive 2012/19/EU (WEEE) |
| Colour |
Orange |
| Localization |
English |
| Operating Temperature (T-T) |
-20-75°C |
| Operating Voltage |
300 V |
| RoHS Compliant |
Compliant |
| Storage Temperature (T-T) |
-20-75°C |
| UL Listed |
Yes |
| WEEE Compliant |
Out of Scope |
