| American Wire Gauge |
18AWG |
| Amperage |
4.9A |
| Application/Usage |
low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, ); line level audio; computer communication; panel wiring |
| Cable Length |
500m |
| Conductor Count |
2 |
| Conductor Material |
Tinned Copper |
| CPR Euroclass Rating |
Dca-s1,d1,a1 |
| Diameter |
6.0mm |
| Environmental Certification |
Non-Halogenated; RoHS Compliant |
| Environmentally Friendly |
Yes |
| Features |
18 AWG Stranded (16x30) Tinned Copper Conductors; 20 AWG (7x28) TC Drainwire; CPR Euroclass Dca-s1,d1,a1; LSZH (Low Smoke Zero Halogen) Outer Jacket; Non-Halogenated; Operating temperature up to 80°C; Overall Beldfoil Shield (100% coverage); Polyethylene Insulation; Suitable for Indoor and Outdoor applications; Sunlight Resistance |
| Indoor/Outdoor |
Indoor; Outdoor |
| Insulation Material |
PE (Polyethylene) |
| Jacket Material |
LSZH (Low Smoke Zero Halogen) |
| Limited Warranty |
1-Year |
| Material |
Tinned Copper |
| Number of Conductors |
2 |
| Number of Pairs |
1 |
| Package Type |
Reel/Spool |
| Product Line |
Classics |
| Product Type |
Multi-Pair Cable |
| Shielding |
Yes |
| Solid or Stranded |
Stranded |
| Voltage Rating |
300V |
| Weight |
48.60kg |
| Maximum Operating Temperature |
80°C |
| CE Marking |
Yes |
| Certifications & Standards |
EN 50290-2-20; IEC 60332-1-2; IEC 60332-3-24; IEC 60754-1; IEC 60754-2; IEC 61034-2; IEC 62821-1; UL 1581 sec 1200 |
| Colour |
Orange |
| Localization |
English |
| Operating Temperature (T-T) |
-45-80°C |
| Operating Voltage |
300 V |
| RoHS Compliant |
Compliant |
| Storage Temperature (T-T) |
-45-80°C |
| UKCA Marking |
Yes |
| WEEE Compliant |
Compliant |
