The Geofire Weatherproof Door Holder (3-59-0801-G008) is a 230V AC, IP65-rated electromagnetic fire door holder for wall mounting. It holds fire doors open for convenient access through busy doorways and releases them to close when the fire alarm is triggered.
The magnet and keeper plate are both made from zinc-plated steel, and the magnet is sealed against water ingress to IP65. This makes it suitable for most building types and particularly for outdoor and maritime use. Electrical connection is made through the IP65 connector supplied with the magnet.
Key features
- Robust zinc-plated steel construction
- 1200N holding force
- Sealed against water ingress to IP65
- IP65 electrical connector supplied
- Supplied complete with keeper plate
- Suitable for outdoor and maritime applications
Technical specifications
- Part number: 3-59-0801-G008 (230V AC version)
- Electrical supply: 230V AC
- Power rating: 10W
- Holding force: 1200N
- Residual force: 20N max
- Ingress protection: IP65
- Ambient temperature: -30°C to +80°C
- Weight: 2.0kg
What's in the box
- Electromagnet assembly
- Keeper assembly
- IP65 connector
