The Advanced EXP-007 is the 2-way relay output card for the ExGo Remote Status Indicator (RSI). It adds two individually programmable, volt-free, 1A-rated outputs to the RSI, avoiding the cost of separate ancillary relay hardware.
The card connects directly to the RSI motherboard, and each output can be programmed for any output function the ExGo system allows, so it suits more complex cause-and-effect arrangements. Mounting pillars are provided on the RSI back box.
Key features
- 2 individually programmable outputs
- Volt-free contacts, each rated 30V AC/DC 1A
- Fast response
- Optional fail-safe set-up
- Programmed from the on-board keypad
- Compatible with the ExGo RSI panel only (the 8-way card, EXP-008, is for the ExGo control panel)
Technical specifications
-
Outputs: 2 x volt-free, individually programmable
-
Contact rating: 1A 30V AC/DC maximum
-
Power supply: 24V DC, taken from the RSI motherboard
-
Dimensions (H x W x D): 70 x 105 x 18mm
-
Compatibility: ExGo Remote Status Indicator (EX-3020, EX-3021, EX-3030, EX-3031)
-
Limitations: Only one relay output card can be fitted per RSI
-
Supplied: Loose, for fitting on site
