The Nittan EV-AV2 Base (part no. F14-85011) is an Evolution analogue addressable combined sounder and beacon with an integral detector base. It gives both an audible alarm and a flashing light to warn occupants of a fire, which helps meet DDA requirements.
It uses the Evolution FSK protocol and is certified to EN 54-3. The base version has a fully integrated detector base.
Key features
- Combined sounder and beacon with integral detector base
- Evolution FSK protocol
- EEPROM addressed with a programmer
- Low and high output settings
Technical specifications
- Operating voltage: 24 to 38 V DC
- Quiescent current: 200 µA
- Alarm current, sounder and beacon active: 9.5 mA (low output) / 14 mA (high output)
- Standard: EN 54-3:2001 + A1:2002 + A2:2006
- Part number: F14-85011
