The Zeta Fyreye MKII-ISO is an addressable isolator base and cover for Zeta Fyreye MKII protocol addressable fire alarm systems. It provides short circuit isolation on the detection loop.
Key features
- Loop short circuit isolator base supplied with cover
- For Fyreye MKII addressable systems
- Loop connections: IN+, IN-, OUT+, OUT-
Technical specifications
- Part number: 80-0918
- Supply voltage: 17-28V DC
- Quiescent current: 50µA @ 24V
- Alarm current: 7mA @ 24V
- Operating temperature: -20°C to 90°C (non-condensing or icing)
- Size: 100 x 33mm
- Weight: 90g
