The Zeta Infinity ID2/REP is a fully functional LCD repeater panel for the Zeta Infinity ID2 intelligent 2-wire fire alarm system. It shows alarms and faults from the ID2 panel at a second location.
It connects to the ID2 panel over RS485 using four cores (two for power, two for data). Up to 8 repeaters can be connected per system; the first two can be powered from the panel, with further repeaters needing an external 24 V supply.
Key features
- Repeats alarms and faults from the Infinity ID2 panel
- Can be configured to start and stop panel sounders, silence buzzers and reset the panel
- Each repeater individually configurable for which commands it can send
- Each repeater can run in a different language
- Up to 8 repeaters per system
- RS485 data connection
Technical specifications
- Model: ID2/REP
- Supply voltage: 29 V DC nominal (19-30 V DC)
- Operating current: 40 mA typical
- Fault output: 1 x fault relay, SELV at 1 A (normally energised)
- Maximum repeaters per system: 8
- Connection: RS485
- Enclosure size: 364 x 302 x 90 mm
- Cable entries: 15 x 19 mm top entries
- Operating temperature: -5 to +40 °C
- Humidity: up to 95% non-condensing
