The HAES Esento Remote Display Unit (XL-RDU) is an LCD fire alarm repeater panel that can operate as fully functional or passive. It is suitable for the Esento conventional panel range (not Eclipse panels) and can be used on an Esento network to display and control events across the entire network.
It has a 4 x 40 character backlit LCD, full system control and a USB input for uploading or downloading the panel program from a PC.
Key features
- 4 x 40 character backlit LCD display
- Full system control
- Fire and fault outputs
- Remote key switch input and PSU fault inputs
- USB input for PC program upload and download
- Test mode with or without sounders; disable zones, sounder outputs, aux outputs and delays
Technical specifications
- Enclosure: 1.2mm mild steel, IP30, Interpon powder coat (colour ref MW334E)
- Cable entry: 20mm knockouts in the top and rear of the cabinet
- Dimensions: 305mm W x 204mm H x 42mm D
- Display: 4 x 40 character backlit LCD
- Input voltage: requires 24V DC supply
- Inputs: optional key switch input
- Outputs: 1 x Fire, 1 x Fault, 24V DC
- Communication wiring: fault tolerant wiring needs 4-core (min 1.5mm) fireproof cable; legacy radial wiring needs 2-core (min 1.5mm) fireproof cable
