HAES Esento Eclipse 2 Zone Conventional / Twin Wire Fire Panel (ECL-2)

The HAES Esento Eclipse 2 zone (ECL-2) is a conventional fire alarm control panel that can also run in Twin Wire mode. Eclipse panels offer HAES's most popular programming features, including false alarm management, Twin Wire mode and non-latching zones, in a compact enclosure.

Twin Wire mode is selected by DIL switch. Note that Eclipse panels do not support networking or repeater panels.

Key features

• 2 conventional or Twin Wire detection zones
• Twin Wire selection by DIL switch
• Controls activated by key switch or code entry
• Integral detector removal monitoring
• 1.25A switch mode power supply, nominal 27V DC
• 2 monitored sounder outputs; alarm load 800mA shared between outputs
• 2 voltage-free changeover relays (1 x Fire, 1 x Fault)
• Class change and alert inputs; fire and fault switched -ve outputs
• False alarm mode and test mode with or without sounders
• Disable zones, sounder outputs and aux outputs

Technical specifications

• Enclosure: 1.2mm mild steel, IP30, Interpon powder coat (colour ref MW334E)
• Cable entry: 20mm knockouts in the top and rear of the cabinet
• Dimensions: back box 300mm W x 250mm H x 80mm D; lid 308mm W x 260mm H x 23mm D
• Mains supply: 1.25A internal switch mode PSU, nominal 27V DC
• Battery capacity: 2 x 3.2Ah 12V VRSLA
• Detection zones: 2 x conventional or Twin Wire, EOL 4K7
• Sounder circuits: 2 x monitored, fused at 500mA (resettable), EOL 4K7
• On-board relays: 1 x Fire, 1 x Fault, 3A 30V volt-free changeover
• Outputs: 1 x Fire, 1 x Fault, 40mA switched -ve
• Switch inputs: class change and alert (pulsing)
• Intrinsically safe mode: selectable per zone
• False alarm management: type A dependency mode, LPCB approved
