Advanced EXP-010 Manual Release Button (EN12094-3 Type B) - no key included

The Advanced EXP-010 is a yellow Manual Release Button approved to EN 12094-3 Type B, for use with the ExGo extinguishing and suppression control panels. It incorporates a latching push-button switch: break the glass and press the button to activate the circuit, then press the reset switch to deactivate.

It is compatible with the ExGo gas extinguishing panel and remote status indicator panel input circuits. Installation requires the EXP-005 switch EOL module to terminate the switch input circuit. Multiple units can be wired in series on one input circuit. The key to open the housing is not included (spare key EXS-003).

Key features

• Latching push-button manual release
• Robust die-cast aluminium housing with door aperture angle greater than 180°
• Operating instructions in symbol form for EN 54-11 compliance
• Replaceable door label
• Red LED for optical indication of activation
• Easy-to-replace standardised glass plate
• Housing opens with a key (not included; EXS-003)

Technical specifications

• Approvals: EN 12094-3:2003 (0786-CPD-20251), EN 54-17
• Dimensions (H x W x D): 126 x 126 x 35mm
• Protection class: IP43
• Temperature: -20°C to +60°C continuous; -25°C to +70°C (max 12 hours)
• Humidity: 95% non-condensing
• Activation module: EXP-005 switch EOL module (required)
• Cable glands: 2 x 20mm (top or bottom entry)
• Weight: 420g
