Advanced MXM-503-SSB Semi-Flushing Bezel -Stainless steel brushed - Large

The Advanced MXM-503-SSB is a brushed stainless steel semi-flushing bezel for MxPro 5 series control panels in the large or deep enclosure. It gives a neat, semi-recessed installation with a high-quality finish, and pairs with the brushed stainless steel MXM-524 series spare doors.

Advanced's MxPro 5 stainless steel finish is grain-matched, so the grain patterns of the door and the matching semi-flushing bezel run in the same direction for a consistent, high-quality installed look. When recessing, allow an extra 5mm clearance on all sides so the bezel can be fitted to the back box; the outer door always stands proud of the finished surface.

Key features

• Brushed stainless steel finish
• Semi-flush fitting for MxPro 5 large and deep enclosures
• Picture-frame effect with 30mm flange (standard MxPro 5 bezel design)
• Grain-matched with MxPro 5 brushed stainless steel doors
• Back box carries an identification mark for positioning pilot drill holes

Technical specifications

• Part code: MXM-503-SSB
• Finish: Brushed stainless steel
• Bezel dimensions: H475 x W450mm
• For use with: MxPro 5 large/deep enclosures
• Flange (MXM-503 bezel): 30mm
• Back box recessing depth (MXM-503 large enclosure bezel): 105mm
• Recessing clearance: Extra 5mm on all sides
• Standard painted version: MXM-503 (RAL 7035)
