| American Wire Gauge |
23AWG |
| Application/Usage |
Premise Horizontal Cable, Ethernet up to 10GBASE-T, Wi-Fi 6, Wi-Fi 5, Surveillance, HDBaseT, PoE++, PoE+, PoE, Noisy Environments |
| Cable Length |
304m |
| Cable Type |
F/UTP |
| Conductor Count |
8 |
| Conductor Material |
Bare Copper |
| Diameter |
6.7mm |
| Environmental Certification |
REACH; RoHS Compliant; WEEE |
| Environmentally Friendly |
Yes |
| Features |
100% Shield coverage; 23 AWG Solid Bare Copper Conductors; 500MHz Frequency; Category 6A Enhanced Premise Horizontal Cable; F/UTP - Foil Shielded; Flamarrest PVC-LS Jacket; Plenum-CMP Rated; Small 0.265" Diameter; Suitable for Wi-Fi 6 and Noisy Environments; Supports PoE++ (up to 100W) |
| Indoor/Outdoor |
Indoor |
| Insulation Material |
FEP (Fluorinated Ethylene Propylene) |
| Jacket Material |
PVC (Polyvinyl Chloride) |
| Material |
Copper |
| Number of Conductors |
8 |
| Number of Pairs |
4 |
| Package Type |
Reel/Spool |
| Product Line |
10GXW |
| Product Series |
10GXW |
| Product Type |
Connector Cables |
| Shielding |
Yes |
| Solid or Stranded |
Solid |
| Voltage Rating |
300V |
| Weight |
16.78kg |
| CE Marking |
Yes |
| Certifications & Standards |
ANSI/NEMA WC-66; ANSI/TIA-568.2-D Category 6A; CMP; CMP-LP (0.5A); EU Directive 2012/19/EU (WEEE); FT6; IEC 61156-5; IEEE 802.3bt Type 1, Type 2, Type 3, Type 4; ISO/IEC 11801-1; NFPA 262 Plenum (UL 910); REACH; S-116-732 |
| Colour |
Blue |
| Localization |
English |
| Operating Temperature (T-T) |
-20-75°C |
| RoHS Compliant |
Compliant |
| Storage Temperature (T-T) |
-20-75°C |
| WEEE Compliant |
Out of Scope |
