Shop all Belden
Belden 4200ULV.01305 16/2 Stranded Bare Copper Security and Sound Cable, LSZH B2ca, 305m, White
SKU: 4200ULV.01305Brand: Belden
| Available to order | Qty | Delivery |
|---|---|---|
| Pre-order | 0 | Lead time 2 to 6 weeks |
Belden 4200ULV.01305 16/2 Stranded Bare Copper Security and Sound Cable, LSZH B2ca, 305m, White
£697.20
Genuine stockBrand new, boxed
1 year warrantyPlus statutory rights
Secure checkoutEncrypted payments
Trade accounts30 day credit
Key featuresFull details
- Low Smoke Zero Halogen insulation and jacket
- CPR B2ca Euroclass rating
- Sunlight Resistance (Black Only)
- 19x29 Stranding
- Ripcord provided under sheath
- 150 N (34 lbf) Max. Pull Tension
Frequently bought together
Belden
Belden 4200ULW.00305 2x16 AWG BC Audio Cable, LSZH, CCA, Grey, 305m
Sale price£664.00
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Belden
Belden 4200ULW.01305 2x16 AWG BC Audio Cable, LSZH, CCA, 305m, White
Sale price£664.00
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Belden
Belden 4201FE.00500 16-3 Stranded BC Shielded Security and Commercial Audio Cable, Polypropylene Insulation, LSZH Jacket with Ripcord, 500m Reel, Gray
Sale price£1,278.80
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Belden
Belden 4202ULW.00500 16-4 Security and Commercial Audio Cable, LSZH Jacket with Ripcord, CPR Cca, 500m Reel, Grey
Sale price£1,885.75
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Belden
Belden 4300FE.00100 18/2 AWG Stranded BC Security and Commercial Audio Cable, Beldfoil, LSZH Jacket Grey, CPR Eca, 100m Reel
Sale price£185.35
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Product details
Security and Commercial Audio Cable, 2-16 AWG stranded bare copper conductors with Low Smoke Zero Halogen insulation, LSZH jacket with ripcord, CPR B2ca.
Main Features
- Low Smoke Zero Halogen insulation and jacket
- CPR B2ca Euroclass rating
- Sunlight Resistance (Black Only)
- 19x29 Stranding
- Ripcord provided under sheath
- 150 N (34 lbf) Max. Pull Tension
- 56 mm (2.2 in) Minimum Installation Bend Radius
- 13.8 Ohm/km Nom. Conductor DCR
- 105 pF/m Nom. Capacitance Cond-to-Cond
- Halogen Amount = Zero
Specifications
| American Wire Gauge | 16AWG |
|---|---|
| Amperage | 6.3A |
| Application/Usage | Intercom/PA Systems; Sound/Audio Systems |
| Cable Length | 305m |
| Conductor Count | 2 |
| Conductor Material | Bare Copper |
| CPR Euroclass Rating | B2ca-s1a,d1,a1 |
| Diameter | 5.6mm |
| Environmental Certification | Halogen Free Compliance; Non-Halogenated; RoHS Compliant |
| Environmentally Friendly | Yes |
| Features | 105 pF/m Nom. Capacitance Cond-to-Cond; 13.8 Ohm/km Nom. Conductor DCR; 150 N (34 lbf) Max. Pull Tension; 19x29 Stranding; 56 mm (2.2 in) Minimum Installation Bend Radius; CPR B2ca Euroclass rating; Halogen Amount = Zero; Low Smoke Zero Halogen insulation and jacket; Ripcord provided under sheath; Sunlight Resistance (Black Only) |
| Indoor/Outdoor | Indoor; Outdoor |
| Insulation Material | LSZH (Low Smoke Zero Halogen), |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Material | Bare Copper |
| Package Type | Reel/Spool |
| Product Type | Speaker Cable |
| Thickness | 1mm |
| Maximum Operating Temperature | 70°C |
| Additional Information | Revision Date: 03-09-2026; Revision Number: 0.15 |
| Certifications & Standards | IEC 60332-1-2; IEC 60754-1; IEC 60754-2; IEC 61034-2; IEC 62821-1; UL 1581 sec 1200 |
| Colour | White |
| Localization | English |
| Operating Temperature (T-T) | -20-70°C |
| RoHS Compliant | Compliant |
| Storage Temperature (T-T) | -30-70°C |
| WEEE Compliant | Out of Scope |
Datasheet
Belden 4200ULV.01305 16/2 Stranded Bare Copper Security and Sound Cable, LSZH B2ca, 305m, White Need the datasheet? Our team will email it to you. Request datasheet
Belden 4200ULV.01305 16/2 Stranded Bare Copper Security and Sound Cable, LSZH B2ca, 305m, White
£697.20
