Name: Belden 6504FE 003U1000 22-6 Security and Sound Cable, Shielded, CMP, Beldfoil Shield and Flamarrest Jacket with Ripcord, 305m UnReel, Orange
Brand: Belden
SKU: 6504FE 003U1000
Price: 507.55 GBP
Availability: InStock

Belden 6504FE 003U1000 22-6 Security and Sound Cable, Shielded, CMP, Beldfoil Shield and Flamarrest Jacket with Ripcord, 305m UnReel, Orange

Roll over image to zoom in Click on image to zoom

Security and Sound Cable, Plenum-CMP, 6-22AWG stranded bare copper conductors with Flamarrest insulation, Beldfoil shield and Flamarrest jacket with ripcord.

Main Features

Shielded security and sound cable
Plenum-CMP rated for safety
6-22AWG stranded bare copper conductors
Beldfoil shield for enhanced protection
Flamarrest jacket with ripcord
305m UnReel for easy installation
Orange color for visibility

Specifications

American Wire Gauge	22AWG
Cable Length	305m
Conductor Count	6
Conductor Material	Bare Copper
Device Supported	Audio/Speaker; Intercom/PA; Noisy Environment; Power-Limited Controls; Security System
Environmental Certification	RoHS 2; WEEE
Indoor/Outdoor	Indoor
Insulation Material	PVC-LS
Jacket Material	PVC-LS
Jacket Type	Standard
Limited Warranty	10-Year
Material	Bare Copper; PVC
Number of Conductors	6
Package Type	Reel-in-a-Box
Packaged Quantity	305
Product Series	Security & Sound
Product Type	Burglar Alarm Cable
Shielding	Yes
Solid or Stranded	Stranded
Colour	Orange
Fibre Category	OM3
Manufacturer	Belden CDT, Inc
RoHS Compliant	Compliant
WEEE Compliant	Compliant

Belden 6504FE 003U1000 22-6 Security and Sound Cable, Shielded, CMP, Beldfoil Shield and Flamarrest Jacket with Ripcord, 305m UnReel, Orange
