The C-TEC QT602EM is the magnetic reset version of the QT602E programmable addressable call point for C-TEC's Quantec Addressable Call System. It has an iconised label, a Call button, a red/green confidence light and a remote jack socket, and it is reset magnetically instead of with a reset button.
Key features
- Programmable addressable call point for the Quantec Addressable Call System
- Iconised Call control with magnetic reset
- Red/green confidence LED
- Can make up to 5 levels of call: Standard, Ensuite, Help Required, Emergency, Presence and Attendance (depending on configuration and ancillary devices used)
- Attack and Attendance calls can also be made when connected to a compatible slave infrared receiver
- Remote jack socket for optional tail call leads/pear pushes, pressure mats and movement detectors
- Can be programmed to operate in many different ways using a QT423 configurator
- Connections for slave devices such as ceiling pulls, overdoor lights, slave call points and slave infrared receivers
Technical specifications
-
Order code: QT602EM (magnetic reset version of the QT602E)
-
System: C-TEC Quantec Addressable Call System
-
Power requirements: Nominal 24V DC (from Quantec controller/network)
-
Quiescent current: Less than 3mA
-
Alarm current: 14mA
-
Indicators: Red/green confidence LED
-
Connections: Net +, Net -, R, G, L+, SW, IR, SLV
-
Remote jack socket: Onboard 6.35mm
-
Onboard sounder / infrared receiver: No / No
-
Mounting: Standard UK 25mm single gang flush or surface back box
-
Construction: Plastic
-
IP rating: IP20
-
Operating conditions: -5ºC to +40ºC, max. 95% relative humidity
