The Comelit UBK3-L is a 3-user Ultra building kit for video door entry, pairing a surface-mounted Ultra entrance panel with a LOGOS monitor on the 2-wire Simplebus 2 platform. It suits homes, small residential blocks, offices and commercial premises.
Key features
- Simplebus 2 two-wire system, supplied programmed and ready to use
- Surface-mounted Ultra series audio/video entrance panel (art. UT2020/4) with call push-buttons (art. UT9211M)
- LOGOS series door entry monitor with handset (art. LS8701), 4.3in colour screen, quick to configure using NFC
- Die-cast aluminium panel frames for high weather resistance; entrance panel rated IP65 and IK08
- Twilight sensor switches off the name-card backlighting during daylight
- Includes the accessories needed to build the system
Specification
| Product code |
UBK3-L |
| Brand |
Comelit-PAC |
| Range |
Ultra building kit (UBK) |
| Users |
3 |
| System |
Simplebus 2 (2-wire) |
| Entrance panel |
Ultra UT2020/4, surface mounted |
| Monitor |
LOGOS LS8701 with handset |
| Protection |
IP65, IK08 |
| Additional panel code |
A-BKUV3S |
