Comelit GDX 6 Button Compact Functional Entrance Panel Surface

The Comelit EPCOS-006 is a GDX5 compact functional entrance panel with 6 call buttons, for surface mounting, from Comelit-PAC. In a functional panel each button is dedicated to one address, so a single press calls that flat or office. It has an anti-vandal design suited to building entrances, car park barriers and help points.

Key features

• 6 functional call buttons, each dedicated to one address
• Surface-mount compact panel
• Anti-vandal 2.5 mm grade 316 stainless steel faceplate secured with six tamper-proof security screws
• IP66 stainless steel buttons
• Backlit LCD for user messages and engineering settings
• Optional integrated HF or LF access control reader
• Engraved button labels; Braille and high-visibility options for Equality Act compliance
• Removable plug-in terminal blocks and hinged chassis for easy installation

Technical specifications

• Product code: EPCOS-006 (compact, surface mount, functional, 6 buttons)
• Audio: duplex
• Access reader options: integrated HF or LF; external via PAC access control; or none
• Power input: 12 V DC
• Power requirement: 0.35 A excluding locks
• Distance to connected inputs: 100 m maximum cable run
• Recommended cabling: 6-core 24 AWG alarm cable / CW1308 (unscreened); 1 x 2-core 1 mm to door lock
• Dimensions: 176 x 303 x 65 mm (W x H x D)
• Weight: approx. 2 kg
• Operating temperature: -10 °C to +35 °C
• Environment: IP66
• Standards: UKCA, CE, WEEE
• Warranty: 5 years against electronic failure
