The Comelit EPRF-004 is the LF RFID access control reader for GDX5 entrance panels from Comelit-PAC. It fits inside the entrance panel behind a vandal-resistant polycarbonate (Lexan) window in the stainless steel faceplate, so residents and staff can open the door with an ID device as well as by calling. It can be added to any GDX5 entrance panel, including later, with no extra cabling.
Key features
- Integrated LF RFID reader for GDX5 entrance panels
- No additional cabling needed
- Can be added to an installed entrance panel later
- Built-in GDX access control stores up to 1,000 ID device records
- Valid and invalid reads confirmed on the panel LCD and by tone
- Fobs can be managed locally at the panel or remotely via the cloud-hosted platform
- Lexan window with raised tactile symbol and contrasting colours for Equality Act compliance
Technical specifications
- Product code: EPRF-004
- Technology: RFID, LF
- Read distance: up to 10 mm
- ID device capacity (GDX access control): up to 1,000
- Supported format: PAC (low frequency)
- Compatible with: GDX5 compact and mitre bezel entrance panels
