The CQR FP2/WH/EDR is a white, single-pole, surface-mounted manual call point from the Deedlock by CQR range. Deedlock FP2 call points are made for access control, fire and specialist applications; a white unit is typically used on access control systems, such as emergency door release, so it is not confused with a red fire alarm call point. It is key resettable and works on 12 or 24V DC systems.
Key features
- Single-pole switching
- Key resettable
- Designed for access control and specialist applications
- Lift-up cover and choice of wording available
- CE marked and RoHS compliant
Technical specifications
- Part number: FP2/WH/EDR
- Type: single pole, resettable
- Colour: white
- Voltage: 12/24V DC
- Contact rating: 12A 125/250V AC
- IP rating: IP44
- Operating temperature: -10°C to +55°C
- Dimensions: 85mm (h) x 85mm (w) x 55mm (d)
- Status display: no; sounder: no; cover: not included
