The CQR PASP1 is a white, single-push personal attack (panic) button for intruder alarm and hold-up systems. It gives a simple, discreet way to raise the alarm when a potential threat arises. The button latches when pressed, shows an indicator to confirm activation and is reset with a key. Its output can be set to normally open or normally closed.
Key features
- Single-push operation
- Latching, with visual indicator to show activation
- Selectable normally open or normally closed output
- Key resettable (spare keys available)
- 5 screw terminals
- Also available in stainless steel or brass
Technical specifications
- Part number: PASP1
- Security grade: Grade 1
- Environmental class: II
- Standards: EN 50131-1, EN 50130-5
- Switch rating: 12V DC, 500mA
- Material: HIPS, white
- IP rating: IP3X
- Operating temperature: -10°C to +40°C
- Dimensions: 70mm (h) x 53mm (w) x 27mm (d)
- Mounting: surface
- Warranty: 2 years
