Name: Dahua DH-IPC-HDW2449TM-S-IL-Black WizSense 4MP Smart Dual Illumination IP Eyeball Camera, Fixed Lens, 30m IR, Black
Brand: Dahua Technology
SKU: DH-IPC-HDW2449TM-S-IL-Black
Price: 84.10 GBP
Availability: InStock

Dahua DH-IPC-HDW2449TM-S-IL-Black WizSense 4MP Smart Dual Illumination IP Eyeball Camera, Fixed Lens, 30m IR, Black

Roll over image to zoom in Click on image to zoom

Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.

Main Features

4-MP 1/2.9" CMOS image sensor, low luminance, and high definition image
Outputs max. 4 MP (2688 x 1520) at 20 fps, and supports 2560 x 1440 at 25/30 fps
H.265 Codec, high compression rate, ultra-low bit rate
Built-in warm light/IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.
ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
Intelligent monitoring Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human)
Supports max. 256 G Micro SD card built in MIC
12 VDC/PoE Power supply, easy for installation
IP67 Protection

Specifications

Connectivity Technology	Wired
Diameter	121.90mm
Effective Camera Resolution	4MP
Environmental Certification	CE; UL
Environmentally Friendly	Yes
Features	12 VDC/PoE power supply, easy for installation.; 4-MP 1/2.9" CMOS image sensor, low luminance, and high definition image.; Built-in warm light/IR LED, the max. illumination distance is 30 m and the max. warm light distance is 30 m.; H.265 codec, high compression rate, ultra-low bit rate.; Intelligent monitoring Intrusion, tripwire (the two functions support the classification and accurate detection of vehicle and human).; IP67 protection.; Outputs max. 4 MP (2688 x 1520) at 20 fps, and supports 2560 x 1440 at 25/30 fps.; ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.; Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.; Supports max. 256 G Micro SD card built in MIC.
Field of View	Diagonal; Horizontal; Vertical
Focal Length	2.8mm; 3.6mm
Form Factor	Eyeball
Height	99.10mm
Image Sensor Type	CMOS
Indoor/Outdoor	Outdoor
Ingress Protection Rating	IP67
Input Voltage	12V DC
Lens Mount Type	M12 (S-Mount)
Lens Type	Fixed
Limited Warranty	3-Year
Maximum Aperture	f/1.6
Maximum Focal Length	3.60mm
Maximum Resolution	2688 x 1520
Maximum Video Resolution	2688 x 1520
Network (RJ-45)	Yes
Night Vision	Yes
Night Vision Type	Infrared (IR)
Product Line	WizSense
Product Series	WizSense
Product Type	Network Camera
Storage Type	SD Card
Video Resolution	2688 x 1520
Weight	0.46kg
Wide Dynamic Range	Yes
Maximum Operating Temperature	60°C
Colour	Black
Longest Shutter Speed	1/3 Second
Manufacturer	Zhejiang Dahua Technology Co., Ltd.
Maximum Frame Rate	30fps
Minimum Focal Length	2.80mm
Minimum Illumination	0.0006lux
Minimum Operating Temperature	-40°C
Night Vision Distance	30.00m
Number of IR LEDs	1
Operating Humidity	95%
RoHS Compliant	Compliant
Shortest Shutter Speed	1/100000 Second
Video Formats	H.264 / AVC; H.264 Baseline Profile; H.264 High Profile; H.265 / HEVC; MJPEG; Smart H.264+; Smart H.265+
WEEE Compliant	Compliant
