Name: Elmdene FIREFOM-12-8 8-Way Power Supply Unit Interface Relay, 12V DC
Brand: Elmdene by Potter
SKU: FIREFOM-12-8
Price: 22.75 GBP
Availability: InStock

Elmdene FIREFOM-12-8 8-Way Power Supply Unit Interface Relay, 12V DC

Roll over image to zoom in Click on image to zoom

12V Interface Relay provides 8 individually fused outputs. Each output is selectable to be either permanently on or switched via a remote signal from a Fire Panel or other control device

Main Features

Available in 12V DC or 24V DC models
4, 8, 12 independantly controlled outputs
Multiple Trigger configurations
Contact rating: 8A @ 12V dc / 4A @ 24V dc
Each output selectable for switched,
permanently on or disabled
LED indication when 'Relay Energised'
Low current consumption
Standalone device - retrofit into any boxed
12Vdc or 24Vdc PSU

Specifications

Compatibility	24V dc PSU; Retrofit into any boxed 12V dc
Contact Type	NO/NC (Combination)
Environmental Certification	RoHS Compliant
Environmentally Friendly	Yes
Features	LED Indicator
Form Factor	Standalone
Height	35.00mm
Limited Warranty	3-Year
Maximum Operating Voltage	14V
Number of Channels	8
Product Line	Access
Product Series	ANCILLERIES
Product Type	Relay Interface Module
Width	73.00mm
Manufacturer	Potter Electric Signal, LLC
RoHS Compliant	Compliant
Switching Current	8A
WEEE Compliant	Compliant
