The EMS SmartCell wireless wall-mounted sounder VAD (white body, red flash) is a fully wireless sounder beacon for the EMS SmartCell wireless fire system. It is individually addressed at the SmartCell control panel or the SmartCell Intelligent Wireless Zone Monitor (iWZM), and combines an EN 54-3 sounder with an EN 54-23 visual alarm device (VAD) using bidirectional 868MHz communication.
Key features
- Fully wireless: quick and easy to install
- EN 54-23 visual alarm device (red flash, W-3-5.11)
- 32 selectable sounder tones, up to 95dB(A) at 1m
- Bidirectional 868MHz wireless communication
- Built-in anti-tamper locking mechanism
- Type B: suitable for indoor and outdoor use (IP33)
- Compatible with the full SmartCell product range; a ceiling-mounted variant is also available
- Third-party certified to EN 54-3, EN 54-13, EN 54-23 and EN 54-25
Technical specifications
-
Colour: White body with red flash
-
Sound output: 95dB(A) at 1m max.
-
Sounder tones: 32 selectable
-
VAD category: W-3-5.11 (red flash)
-
Radio frequency: 868MHz
-
Transmit power: 14dBm / 25mW
-
Signalling protocol: X5
-
Batteries: 3 x 3.6V lithium thionyl chloride (ER14505M)
-
Operating temperature: -10 to +55°C
-
Storage temperature with batteries: -10 to +30°C
-
IP rating: IP33, Type B (indoor/outdoor)
-
Dimensions (Ø x D): 110 x 77mm
-
Weight: 0.20kg
-
Certification: 0359-CPR-00428; EN 54-3, EN 54-13, EN 54-23, EN 54-25
