| IP Video Input |
32-ch | Up to 32 MP resolution | *: The NVR supports up to 8-ch 32/24/16 MP IP video inputs. |
| Incoming Bandwidth |
320 Mbps |
| Outgoing Bandwidth |
400 Mbps |
| HDMI 1 Output |
8K (7680 × 4320)/30Hz, 4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 720/60Hz |
| HDMI 2 Output |
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 720/60Hz |
| VGA Output |
1920 × 1080/60Hz, 1280 × 720/60Hz |
| Video Output Mode |
HDMI1/VGA simultaneous output, HDMI2/VGA independent output |
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) |
| Decoding Format |
H.265+/H.265/H.264+/H.264 |
| Recording Resolution |
32 MP/24 MP/16MP/12 MP/8 MP/7 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF | *: The NVR supports up to 8-ch 32/24/16 MP IP video inputs. |
| Synchronous Playback |
16-ch |
| Decoding Capability |
2-ch@32 MP (30 fps); 3-ch@24 MP (30 fps); 4-ch@16MP (30 fps); 6-ch@12MP (30 fps);10-ch@8 MP (30 fps); 13-ch@6 MP (30 fps);16-ch@5 MP (30 fps);32-ch@2MP(30 fps) |
| Dual-Stream Recording |
Support |
| Stream Type |
Video, Video & Audio |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2 |
| Remote Connection |
128 |
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF(Version 2.2), OTAP |
| Network Interface |
1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Camera Access Protocol |
ONVIF(Version 2.5), RTSP |
| Interface |
24, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
| Power |
≤ 210 W |
| Standard |
IEEE 802.3 af/at |
| eSATA |
1 eSATA interface |
| SATA |
4 SATA interfaces |
| Capacity |
Up to 16 TB capacity for each disk |
| Serial Interface |
2 RS-485 (half-duplex), 1 RS-232 |
| Alarm In/Out |
16/9 |
| USB Interface |
Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0 |
| Ctrl 12V |
Controllable 12 VDC, 1 A power output for external alarm device; The power will be turned on when the alarm output is triggered. | *: The Ctrl 12V power is controlled by alarm output 9. |
| DC 12V |
12 VDC, 1 A power output |
| Power Supply |
100 to 240 VAC, 50 to 60 Hz |
| Consumption |
≤ 15 W (without HDD and PoE off) |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Working Humidity |
10% to 90% |
| Chassis |
19-inch rack-mounted 1.5U chassis |
| Dimension (W × D × H) |
445 × 400 × 75 mm ( 17.5"× 15.7" × 3.0") |
| Weight |
≤ 5 kg (without HDD, 11 lb.) |
| FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
| CE |
EN 55032:2015+A1:2020, ENIEC61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:201 | 9, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020 |
| Obtained Certification |
CE、REACH、WEEE、FCC、CB、RCM、KC、UL |
| EN 303645 |
Support |
| Secure Boot |
Support |
| Secure Component Verification SVC |
Support |
| Password Protection |
Support |
| IP & MAC Address Filtering |
Support |
| HTTPS Encryption |
Support |
| Live View & Playback Stream Encryption |
Support : AES128 |
| IEEE802.1X(EAP-TLS) Network Access Control |
Support |
| Signed Firmware |
Support |
| Others |
Digest authentication: Support | User access log : Support | Centralized certificate management : Support | Brute force delay protection : Support |
