| Connectivity Technology |
Wired |
| Diameter |
2.20" |
| Durability |
Dustproof; Impact Resistant; Waterproof |
| Effective Camera Resolution |
5MP |
| Environmental Certification |
RoHS |
| Environmentally Friendly |
Yes |
| Features |
2D Noise Reduction; 3D Noise Reduction; Automatic White Balance; Back Light Compensation (BLC); Day/Night; Defog; Gain Control; Highlight Compensation (HLC); SD Card Local Storage; Wide Dynamic Range |
| Field of View |
Horizontal; Vertical |
| Focal Length |
2.8mm |
| Form Factor |
Micro Dome |
| Image Sensor Type |
CMOS |
| Indoor/Outdoor |
Indoor |
| Ingress Protection Rating |
IP66; IP67 |
| Input Voltage |
12V DC |
| Lens Type |
Fixed |
| Limited Warranty |
3-Year |
| Maximum Aperture |
F/2 |
| Maximum Focal Length |
2.80mm |
| Maximum Resolution |
1280 x 720 |
| Maximum Video Resolution |
2592 x 1944 |
| Mount Type |
Corner Mount; Junction Box Mount; Pole Mount |
| NDAA Compliant |
Yes |
| Network (RJ-45) |
Yes |
| Night Vision |
Yes |
| Night Vision Type |
Infrared (IR) |
| Product Line |
MB Secure |
| Product Series |
35 |
| Product Type |
Dome Cameras |
| Storage Type |
SD Card |
| Video Resolution |
1280 x 720 |
| Video Signal Format |
NTSC; PAL |
| Weight |
1.21lb |
| Wide Dynamic Range |
Yes |
| Maximum Operating Temperature |
140°F |
| Alternative ADI Part Number |
HX-CD2583G22, HX-CD2543G22, HX-T15F6S |
| Alternative Model Number |
DS-2CD2583G2-IS 2.8MM, DS-2CD2543G2-IS 2.8MM, PCI-T15F6S |
| CE Marking |
Yes |
| Colour |
White |
| Country of Origin |
CN |
| Field of View (Horizontal) |
88.0° |
| Field of View (Vertical) |
65.00° |
| Impact Protection Rating |
IK10 |
| Lens Included |
Yes |
| Longest Shutter Speed |
1/8 Second |
| Manufacturer |
Honeywell International, Inc |
| Maximum Frame Rate |
30fps |
| Minimum Focal Length |
2.80mm |
| Minimum Operating Temperature |
-40°F |
| Night Vision Distance |
98.43' |
| Operating Humidity |
90% |
| Remote Management |
Yes |
| RoHS Compliant |
Compliant |
| Shortest Shutter Speed |
1/32000 Second |
| This product replaced ADI# |
H2W2PC1M, H2W2PER3, H2W4PER3, H2W4PER3V, H2W4PRV3, HC30W25R3 |
| This product replaced Supplier# |
H2W2PC1M, H2W2PER3, H2W4PER3, H2W4PER3V, H2W4PRV3, HC30W25R3 |
| Video Formats |
H.264 / AVC; H.265 / HEVC; MJPEG |
| WEEE Compliant |
Compliant |
