Kentec Sigma CP-R 2 Zone Repeater Panel - 230v (K01020M2)

The Kentec Sigma CP-R K01020M2 is a 2 zone repeater panel with its own mains power supply for Kentec Sigma CP conventional fire alarm control panels. It is compatible with all Sigma CP control panels running operating software version V2.0 or above, and gives full control over the main panel from a second location. Being mains powered, it needs only a two-core data cable from the main panel.

Key features

• Certified to EN54-2 and EN54-4
• Two-wire serial connection to the main panel
• Up to 7 repeaters per system, each addressed 1 to 7 by a DIL switch
• Full control over the main panel
• Volt-free fire and fault contact outputs
• Optional tamper resistant Vision Window (K18002) can be retrofitted

Technical specifications

• Zones: 2
• Supply voltage: 230V AC (+10%/-15%)
• Mains supply fuse: 1.6A 250V
• Power supply DC rating: 24V 1A
• Batteries: two 12V, 7Ah max
• Standby current: 0.075A; alarm current: 0.094A
• Data cable: total length from main panel to last repeater must not exceed 1200m
• Fault and fire contacts: 30V DC 1A
• Cable capacity: 2.5mm² per terminal
• Dimensions: 385 x 310 x 60mm; weight 6kg
• Construction: 1.2mm mild sheet steel, epoxy powder coated, BS 00 A 05 grey
• IP rating: IP30
• Operating temperature: -5°C to +40°C, humidity <95% non-condensing
