The W1A-R470SG-STCK-01 is a surface-mounted outdoor manual call point for conventional (non-addressable) fire alarm systems. It is sealed to IP67 for outdoor use and is fitted with a 470 Ohm alarm resistor and a normally open (N.O.) contact.
It is supplied with a glass and replaces the old part number WCP1A-R470SG-01.
Key features
- Outdoor call point sealed to IP67
- Surface mounting
- 470 Ohm alarm resistor with N.O. contact for conventional zones
- Supplied with glass
- Wide operating temperature range for outdoor locations
Technical specifications
- Type: conventional, surface mounting, outdoor
- Ingress protection: IP67
- Alarm resistor: 470 Ohm, N.O. contact
- Dimensions (W x H x D): 97.5 x 93 x 71 mm
- Weight: 270 g
- Operating voltage: 24 V DC nominal
- Operating temperature: -30°C to +70°C
- Old part number: WCP1A-R470SG-01
