Power Sonic 12v 7Ah Sealed Lead Acid Battery - Flame Retardant (PS-1270FR)
| Stock available | Qty | Delivery |
|---|---|---|
| Poole | 15 | Same day dispatch |
| UK Hub | 0 | None at UK Hub |
- Absorbent Glass Mat (AGM) sealed lead acid construction, maintenance-free
- Gas recombination technology for quick recovery of capacity during charge
- Flame-retardant (FR) version: ABS case and cover rated UL94 V-0
- 5-year float life class (per Power Sonic float life data)
Frequently bought together
Product details
The Power Sonic PS-1270FR is a 12V 7Ah battery in a flame-retardant UL94 V-0 case, a common standby battery for fire and security panels.
The Power Sonic PS-1270FR is a 12V 7Ah sealed lead acid (SLA) battery from Power Sonic’s PS Series general purpose range in the flame-retardant (FR) version, with a UL94 V-0 rated ABS case and cover. Power Sonic engineers these batteries for general purpose float and light cyclic applications, including fire and security systems, emergency lighting, UPS and medical devices.
Key features
- Absorbent Glass Mat (AGM) sealed lead acid construction, maintenance-free
- Gas recombination technology for quick recovery of capacity during charge
- Flame-retardant (FR) version: ABS case and cover rated UL94 V-0
- 5-year float life class (per Power Sonic float life data)
Technical specifications
- Nominal voltage: 12V (6 cells)
- Nominal capacity (20-hour rate): 7.0Ah
- Capacity (10-hour rate): 6.53Ah
- Capacity (5-hour rate): 6.05Ah
- Capacity (1-hour rate): 4.27Ah
- Approximate weight: 1.97 kg
- Dimensions (L × W × H): 151 × 65 × 94 mm
- Height over terminals: 100 mm
- Internal resistance (approx.): 33 mΩ
- Max short circuit discharge current: 196A
- Operating temperature – charge: −20°C to +50°C
- Operating temperature – discharge: −15°C to +60°C
Specifications taken from the Power Sonic datasheet; dimensions have a tolerance of ±2 mm.
Used for: standby power in fire alarm panels, intruder alarms, access control, emergency lighting and UPS equipment. Alternative: Yuasa NP7-12FR.
Frequently asked questions
What does FR mean?
FR is the flame-retardant version, with an ABS case and cover rated UL94 V-0.
What size is the battery?
151 × 65 × 94 mm (100 mm over terminals), weighing approximately 1.97 kg.
What is the design life?
It is in the 5-year float life class, per Power Sonic float life data.
