The Texecom Premier Elite 168 PCB is the control panel circuit board for the Premier Elite 168, supplied as a PCB only. The Premier Elite 168 is a wired intruder alarm control panel with 8 zones expandable to 168, sharing the same programming platform and peripheral devices as the rest of the Premier Elite series.
Key features
- 8 on-board wired zones, expandable to 168
- Hybrid system: accepts wired and wireless expanders
- 16 areas and 200 user codes
- 2,000-event log, time and date stamped
- Plug-on digimodems
- Compatible with Texecom Cloud, Texecom Monitor and Texecom Connect when used with a SmartCom or SmartCom 4G communicator
Technical specifications
- Part number: CAD-0018 (PCB only)
- Maximum zones: 168 (up to 128 wireless)
- Areas: 16
- Maximum keypads: 16
- User codes: 200
- Event log: 2,000 events
