The Videx 8836-1 is an 8000 series audio speaker module with one built-in call button for traditional Videx "4+1" audio door entry systems. It contains the speaker and a fly-lead microphone, and slides into an 8000 series housing frame, which holds it securely in place.
More call buttons can be added with 8000 series button modules. Speech levels for the speaker and microphone are adjusted separately.
Key features
- Speaker and fly-lead microphone that fits easily within an 8000 series frame
- For traditional Videx "4+1" audio systems
- Speech volume adjustment in both directions
- Built-in call button with illuminated name window and replaceable insert
- Expandable with 8842, 8843, 8844 and 8845 button modules (up to 64 call buttons in total)
- Stainless steel front fascia
- Simple, strong slide-in module design
- Backwards compatible with older Videx 800 series front support frames (surface and flush)
Technical specifications
- Part number: 8836-1
- System: "4+1" audio
- Built-in buttons: 1 (tactile microswitch)
- Power: 12 VAC
- Lock output: dry contact CO/NO pair
- Dimensions: 97 (W) x 120 (L) x 30 (D) mm
