The Videx VR120/138-18 is an 18 button VR120 series vandal resistant audio door entry panel for the Videx VX2200 digital system. It is fitted with the VX2200 functional (digital) amplifier, Art.138N.
VR120 panels are 120 mm wide, made from 12 gauge 316 grade stainless steel and rated IP55. They have SPEAK, BUSY and DOOR OPEN call progress LEDs with reassurance tones to help visitors, and each button is identified by 6 mm high engraved characters. A flush back box is standard; surface boxes with rainshield and stainless steel bezel flush boxes are also available.
Key features
- 12 gauge 316 grade stainless steel, IP55 rated panel
- 18 vandal resistant call buttons, with optional high contrast yellow bezels
- SPEAK, BUSY and DOOR OPEN call progress LEDs
- Call progress reassurance tones
- Dry contact lock output
- Timed call, speech and lock release
- Independent speaker and microphone volume adjustment
- Speaker and microphone protected by offset stainless steel mesh; Mylar speaker cone
- Neoprene seal against dust and liquid
- Anti-vandal face plate fixings
Technical specifications
- Part number: VR120/138-18
- System: VX2200 2-wire digital audio (Art.138N functional amplifier)
- Number of call buttons: 18
- Material: 12 gauge 316 grade stainless steel
- Panel protection: IP55
- Panel width: 120 mm
- Fixings: M5 countersunk stainless steel security screws
- LEDs: red (busy), yellow (speak), green (door open)
- Button engraving: 6 mm high characters
- Standard back box: flush mounting, 50 mm deep
- Optional back boxes: surface with rainshield, or flush with stainless steel bezel
