The Videx 8852 is a 2 module 8000 series front support frame and flush back box, with the front frame in an aluminium finish. It is used to flush mount Videx 8000 series audio and video door entry modules.
Flush back boxes can be joined together with the spacers provided when a panel needs more than three modules (for example, two 8852 boxes for a four module panel), and can be combined with 8000 series rainshields to cover cut-outs in the wall.
Key features
- Houses 2 modules of the 8000 series
- Front support frame in aluminium finish; white high impact ABS flush back box
- Waterproof gasket fitted to the front support frame
- Spacers provided to join back boxes for panels of more than 3 modules
- Compatible with all 8000 series audio and video modules, except the CVK8K and CVKC8K video modules (8833-1/C and 8833-2/C)
- Matching rainshield: 8872, or two 8852 boxes with the 8874
Technical specifications
- Part number: 8852
- Housed module size: 2 module
- Front support frame size: 115 (W) x 274 (L) x 22 (D) mm
- Flush back box size: 115 (W) x 263 (L) x 30 (D) mm
- Front support frame finish: aluminium
- Flush back box material: white, high impact ABS plastic
What's in the box
- Front support frame and flush back box
- Waterproof gasket, fixing brackets, hinge screws and central Allen key screw
- Spacers for joining back boxes
