The Videx MTPXBK-RS-MF is a compact surface-mounted Mifare proximity reader for the Videx WS4 Web Access System. It connects to the WS4 controller over an RS485 bus and reads Mifare Classic, Ultralight and Desfire fobs and cards at 13.56 MHz.
It is housed in an IP65 rated, impact-resistant black ABS housing with resin-potted electronics, and is programmed through the WS4 web access software and WS4 smartphone app.
Key features
- Mifare proximity reader for WS4 Web Access
- RS485 bus connection to WS4 controller
- Halo status LED (red, green and orange) and internal sounder
- IP65 rated black ABS surface housing
- Resin-potted electronics
Technical specifications
- Part number: MTPXBK-RS-MF
- Material and colour: surface ABS housing, black
- IP rating: IP65
- Proximity reading type: Mifare Classic, Ultralight and Desfire, 13.56 MHz
- Reading distance: up to 6 cm
- Operating voltage: 9-14 VDC
- Current rating: 130 mA max.
- Working temperature: -20 °C to +50 °C
- Dimensions: 90 (L) x 51 (W) x 27 (D) mm
