The Advanced MXS-501-CP-S is a genuine Advanced spare basecard for the MxPro 5 MX-5100 single-loop fire alarm control panel, supplied mounted on a small-enclosure chassis, programmed, and without loop driver cards.
It allows a damaged or faulty basecard to be replaced while existing loop driver cards are transferred or new ones fitted. Advanced lists a spare MX-5100 basecard PSU separately as MXS-501-PSU (3A); other versions of this basecard are MXS-501-CP-M (medium chassis) and MXS-501-PCB (PCB only).
Key features
- Genuine Advanced MxPro 5 spare basecard
- Supplied programmed
- No loop driver cards fitted
- Mounted on the small-enclosure chassis
- MxPro 5 panel platform: dual flash-based processors with real-time clock and trace diagnostics
- MxPro 5 panel platform: on-board Ethernet (AdvancedLive, UK and Ireland only), USB and RS232, integral P-Bus
Technical specifications
-
Part code: MXS-501-CP-S
-
Manufacturer description: Spare MX-5100 Basecard w Small Chassis - No Loop cards. Programmed
-
For use with: MxPro 5 MX-5100 series single-loop panels
-
Loop driver cards: Not included (MXP-568 Apollo / Hochiki / Argus Vega; MXP-567 Nittan)
-
Spare basecard PSU (listed separately): MXS-501-PSU (3A)
-
Panel loop current: 500mA
-
Panel sounder circuits: 2 x 1A programmable
-
Panel on-board relays: 2 x 1A 30V AC/DC programmable
-
Panel auxiliary supply: 1 x 24V 500mA
-
Panel event log: 5,000 event and diagnostic plus 500 fire
