The ATS1238 Advanced Wireless Data Gathering Panel (DGP) receiver expands the Advisor Advanced panels input capability by up to 32 zones using Carrier Security wireless PIRCam and 868MHz Gen 2 Wireless Sensors: i.e. PIR, Door contact etc. The ATS1238 is typically installed inside the large poly housing and connected to the MI bus interface of the Advisor Advanced panel. The ATS1238 features spatial diversity to minimize wireless signal nulls or dead spots and has a nominal open-air receiving range of 400m. If dead spots need to be eliminated, a 868MHz repeater may be used for the 868Gen2 devices only.
Main Features
Expands the Advisor Advanced panel with 32 wireless zones, including PIR Cameras
Supports a maximum of 8 wireless PIR Cameras
Uses the Carrier Security "Learn Mode" 868MHz Wireless Transmitter Sensors
Installed into the Large Poly housing
Features spatial diversity to minimize wireless signal nulls or dead spots and has a nominal open-air receiving range of 400m
If dead spots need to be eliminated a Carrier Fire & Security 868MHz repeater may be used for 868Gen2 sensors
Powered from MI bus interface of the Advisor Advanced
Up to 16 Fob buttons may be programmed for users to arm and disarm or to control relays
