Name: Belden 2412 003A1000 CAT6+ Enhanced Cable, 4-Pair, U/UTP, CMR, Reel-in-Box, Orange, 305m
Brand: Belden
SKU: 2412 003A1000
Price: 0.75 GBP
Availability: InStock

Belden 2412 003A1000 CAT6+ Enhanced Cable, 4-Pair, U/UTP, CMR, Reel-in-Box, Orange, 305m

Roll over image to zoom in Click on image to zoom

Category 6+ Enhanced Premise Horizontal Cable (350MHz), 4 Pair, 23 AWG Solid Bare Copper Conductors, U/UTP, Riser-CMR, PVC Jacket

Main Features

Experience a simpler way to connect devices with the entire business network
Features Category 6+ cable type for optimal performance and better dependability
PoE feature for your convenience and ease of usage
Fully compatible with network devices

Specifications

American Wire Gauge	23AWG
Application/Usage	Ethernet 1000BASE-T; Ethernet 100BASE-TX; Ethernet 10BASE-T; PoE; PoE+; PoE++; Premise Horizontal Cable
Cable Length	304m
Cable Type	Category 6+
Compatibility	Ethernet 1000BASE-T, Ethernet 100BASE-TX, Ethernet 10BASE-T, PoE++, PoE+, PoE
Conductor Count	8
Conductor Material	Bare Copper
Data Transfer Rate	1Gbps
Device Supported	Network Device
Environmental Certification	CE; China RoHS 2; RoHS 2; WEEE
Environmentally Friendly	Yes
Features	Attenuation Crosstalk Ratio Far-end (ACR-F); Attenuation to Crosstalk Ratio (ACR); Bendable; Equal Level Far End Crosstalk (ELFEXT); Minimized Near-End Crosstalk (NEXT); PoE; PoE+; PoE++; Power Sum Attenuation to Crosstalk Ratio (PSACR); Power Sum Attenuation to Crosstalk Ratio, Far-End (PSACRF); Power-sum Equal Level Far-End Crosstalk (PSELFEXT); Power-sum Near End Crosstalk (PSNEXT)
Frequency	350MHz
Impedance	78Ohm
Indoor/Outdoor	Indoor
Insulation Material	Polyolefin
Jacket Material	Polyvinyl Chloride (PVC)
Jacket Type	Standard
Limited Warranty	10-Year
Material	Bare Copper
Number of Conductors	8
Number of Pairs	4
Package Type	Bulk
Packaged Quantity	305
Product Series	2412
Product Type	Network Cable
Shielding	No
Solid or Stranded	Solid
Colour	Orange
Manufacturer	Belden CDT, Inc
Operating Temperature (T-T)	-20-75°C
RoHS Compliant	Compliant
WEEE Compliant	Compliant
