Belden 4300ULV is a security and sound cable engineered for fire‑critical environments. It features two 18 AWG stranded bare copper conductors with LSZH insulation and jacket, meeting CPR B2ca requirements. The cable is supplied in white on a 305 m reel.
Main Features
Security and Commercial Audio Cable
2-18 AWG stranded bare copper conductors with Low Smoke Zero Halogen insulation
LSZH Jacket with ripcord
CPR B2ca Rated offers enhanced fire performance
Specifications
American Wire Gauge
18AWG
Amperage
5.0A
Application/Usage
Control Systems; Intercom/PA Systems; Sound/Audio Systems
Cable Length
305m
Cable Type
Speaker Cable
Conductor Count
2
Conductor Material
Bare Copper
CPR Euroclass Rating
B2ca-s1a,d1,a1
Diameter
5.5mm
Environmental Certification
Non-Halogenated
Features
Ripcord provided under sheath
Indoor/Outdoor
Indoor
Insulation Material
LSZH (Low Smoke Zero Halogen),
Jacket Material
LSZH (Low Smoke Zero Halogen)
Number of Conductors
2
Product Type
Cable
Cable Style
Security & Commercial Audio Cable
Maximum Operating Temperature
70°C
Additional Information
Installation Min. Bend Radius: 55 mm (2.2 in); Max. Current: 5 Amps per Conductor; Max. Pull Tension: 90 N (20 lbf); Nom. Capacitance Cond-to-Cond: 100 pF/m (30 pF/ft); Nom. Conductor DCR: 21.3 Ohm/km (6.49 Ohm/1000ft); Stationary Min. Bend Radius: 28 mm (1.1 in)
