Name: Belden 4694R 0031000 18-1 RG-6 Solid SC Indoor Riser Coaxial Video Cable, TC Braid Shield, CMR, CMG, 305m Reel, Orange
Brand: Belden
SKU: 4694R 0031000
Price: 3.80 GBP
Availability: InStock

Belden 4694R 0031000 18-1 RG-6 Solid SC Indoor Riser Coaxial Video Cable, TC Braid Shield, CMR, CMG, 305m Reel, Orange

Roll over image to zoom in Click on image to zoom

Belden 4694R is a 75‑ohm RG‑6 SDI coaxial cable designed for indoor riser installations. It features an 18 AWG solid silvered copper conductor with foil and 95% tinned copper braid shielding. Supplied in orange on a 305m reel.

Main Features

75 Ohm SDI Coax
RG-6 coaxial cable supports high-frequency signal transmission
18 AWG Solid Silvered Copper Conductor
PE Insulation
Foil + 95% Tinned copper braid shield
PVC Jacket
CMR-rated cable

Specifications

American Wire Gauge	18AWG
Cable Length	305m
Cable Type	Coaxial
Data Transfer Rate	12Gbps
Device Supported	HDTV; Video Device
Environmental Certification	CE; China RoHS; RoHS 2; WEEE
Environmentally Friendly	Yes
Impedance	75Ohm
Indoor/Outdoor	Indoor
Jacket Type	Standard
Limited Warranty	10-Year
Material	Laminate; Silvered Copper; Tinned Copper
Number of Conductors	1
Package Type	Bulk
Product Series	4694R
Product Type	Cable
Shielding	Yes
Solid or Stranded	Solid
Colour	Orange
Manufacturer	Belden CDT, Inc
RoHS Compliant	Compliant
WEEE Compliant	Compliant
