Name: Belden 5200UE 009U1000 16/2 Security and Commercial Audio Cable, Riser-CMR, 1000' Reel, White
Brand: Belden
SKU: 5200UE 009U1000
Price: 449.95 GBP
Availability: InStock

Belden 5200UE 009U1000 16/2 Security and Commercial Audio Cable, Riser-CMR, 1000' Reel, White

Roll over image to zoom in Click on image to zoom

Security and Commercial Audio Cable, Riser-CMR, 2-16AWG stranded bare copper conductors with polypropylene insulation, PVC jacket with ripcord.

Main Features

16/2 AWG stranded bare copper conductors
Polypropylene insulation for durability
PVC jacket with ripcord for easy installation
Riser-CMR rated for safety
1000' reel for extensive coverage
Suitable for security and commercial audio applications
White color for versatile use

Specifications

American Wire Gauge	16AWG
Application/Usage	Control Circuits; Data Circuits; Initiating Circuits; Monitor/Detection; Notification Circuits
Cable Length	305m
Cable Rating	CMR
Cable Type	Bare Wire
Conductor Count	2
Conductor Material	Bare Copper
Device Supported	Control Circuits; Data Circuits; Initiating Circuits; Monitor/Detection; Notification Circuits
Environmental Certification	RoHS 2; WEEE
Indoor/Outdoor	Indoor
Insulation Material	PO
Jacket Material	PVC
Jacket Type	Standard
Limited Warranty	10-Year
Material	Bare Copper; Polyolefin; PVC
Number of Conductors	2
Number of Pairs	1
Package Type	Reel-in-a-Box
Packaged Quantity	305
Product Series	Security & Sound
Product Type	Audio Cable
Shielding	No
Solid or Stranded	Stranded
Colour	White
Fibre Category	OM1
Manufacturer	Belden CDT, Inc
Operating Temperature (T-T)	-20-75°C
RoHS Compliant	Compliant
WEEE Compliant	Compliant
