Belden 8762ELV.02305 Electronic 20-2 Stranded TC Cable, PE Insulation, Overall Beldfoil Shield, LSZH Outer Jacket, CPR B2ca, 305m Reel, White
SKU: 8762ELV.02305Brand: Belden
| Available to order | Qty | Delivery |
|---|---|---|
| Pre-order | 0 | Lead time 2 to 6 weeks |
Belden 8762ELV.02305 Electronic 20-2 Stranded TC Cable, PE Insulation, Overall Beldfoil Shield, LSZH Outer Jacket, CPR B2ca, 305m Reel, White
£756.80
Genuine stockBrand new, boxed
1 year warrantyPlus statutory rights
Secure checkoutEncrypted payments
Trade accounts30 day credit
Key featuresFull details
- 20 AWG Tinned Copper Conductors
- Overall Beldfoil Shield (100% coverage)
- LSZH (Low Smoke Zero Halogen) Outer Jacket
- CPR Euroclass B2ca-s1,d1,a1
- Sunlight Resistance
- 300 V Voltage Rating
Frequently bought together
Belden
Belden 8762ELW.00305 20-2 Stranded Electronic Cable, TC, PE Insulation, Overall Beldfoil Shield, LSZH Outer Jacket, CCA, 305m Reel
Sale price£722.35
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Belden
Belden 8762ELW.01305 20-2 Stranded TC Electronic Data Cable, PE Insulation, Overall Beldfoil Shield, LSZH Outer Jacket, 305m
Sale price£722.35
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Belden
Belden 8762NH.00152 20/2 Stranded TC PE Insulation Security Cable, 152m Reel, Chrome
Sale price£325.10
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Belden
Belden 8762NH.00305 20/2 Stranded TC PE Insulation Security Cable, 305m Reel, Chrome
Sale price£652.30
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Belden
Belden 8762NH.00500 20/2 Stranded TC PE Insulation Security Cable, 500m Reel, Chrome
Sale price£1,069.30
Pre-Order (Not in Stock)
- Estimated Lead Time: 2-6 Weeks.
Product details
Electronic, 2 Conductor 20AWG (7x28) Tinned Copper, PE Insulation, Overall Beldfoil Shield, LSZH Outer Jacket, CPR B2ca.
Main Features
- 20 AWG Tinned Copper Conductors
- Overall Beldfoil Shield (100% coverage)
- LSZH (Low Smoke Zero Halogen) Outer Jacket
- CPR Euroclass B2ca-s1,d1,a1
- Sunlight Resistance
- 300 V Voltage Rating
- Operating Temperature -45°C to +80°C
- Non-Halogenated
- Tinned Copper Drainwire
- White Jacket Color
Specifications
| American Wire Gauge | 20AWG |
|---|---|
| Amperage | 3.9A |
| Application/Usage | low voltage analog signals (4-20ma, 0-10v, ...); low voltage digital control (24v, ); line level audio; computer communication; panel wiring |
| Cable Length | 305m |
| Compatibility | EU Directive 2011/65/EU (RoHS 2); EU Directive 2015/863/EU (RoHS 2 amendment) |
| Conductor Count | 2 |
| Conductor Material | Tinned Copper |
| CPR Euroclass Rating | B2ca-s1,d1,a1 |
| Diameter | 5.4mm |
| Environmental Certification | Non-Halogenated; RoHS Compliant; Sunlight Resistance |
| Environmentally Friendly | Yes |
| Features | 20 AWG Tinned Copper Conductors; 300 V Voltage Rating; CPR Euroclass B2ca-s1,d1,a1; LSZH (Low Smoke Zero Halogen) Outer Jacket; Non-Halogenated; Operating Temperature -45°C to +80°C; Overall Beldfoil Shield (100% coverage); Sunlight Resistance; Tinned Copper Drainwire; White Jacket Color |
| Impedance | 56Ohm |
| Indoor/Outdoor | Indoor; Outdoor |
| Insulation Material | PE (Polyethylene) |
| Jacket Material | LSZH (Low Smoke Zero Halogen) |
| Material | Alum; Low Smoke Zero Halogen; Poly; Polyethylene; Tinned Copper |
| Number of Conductors | 2 |
| Number of Pairs | 1 |
| Package Type | Reel/Spool |
| Product Line | Classics |
| Product Type | Multi-Pair Cable |
| Shielding | Yes |
| Solid or Stranded | Stranded |
| Voltage Rating | 300V |
| Weight | 46.90kg |
| Maximum Operating Temperature | 80°C |
| Additional Information | Revision Date: 03-09-2026; Revision Number: 0.54 |
| CE Marking | Yes |
| Certifications & Standards | EN 50290-2-20; IEC 60332-1-2; IEC 60332-3-24; IEC 60754-1; IEC 60754-2; IEC 61034-2; IEC 62821-1; UL 1581 sec 1200 |
| Colour | White |
| Localization | English |
| Operating Temperature (T-T) | -45-80°C |
| RoHS Compliant | Compliant |
| Storage Temperature (T-T) | -45-80°C |
| UKCA Marking | Yes |
| WEEE Compliant | Out of Scope |
Datasheet
Belden 8762ELV.02305 Electronic 20-2 Stranded TC Cable, PE Insulation, Overall Beldfoil Shield, LSZH Outer Jacket, CPR B2ca, 305m Reel, White Need the datasheet? Our team will email it to you. Request datasheet
