Name: Belden 8772NH.00500 20-3 Stranded Electronic Cable, TC, Polyolefin Insulation, OS, LSZH / FRNC Jacket, 300V, 500m Reel, Blue
Brand: Belden
SKU: 8772NH.00500
Price: 1144.45 GBP
Availability: InStock

Belden 8772NH.00500 20-3 Stranded Electronic Cable, TC, Polyolefin Insulation, OS, LSZH / FRNC Jacket, 300V, 500m Reel, Blue

Roll over image to zoom in Click on image to zoom

Electronic, 3 ConductorAWG 20 Tinned Copper - Stranded, Polyolefin (PO, PE, PP) insulation, Foil(s) or Copper Tape(s) shielding, LSZH / FRNC jacket , 300V.

Main Features

20 AWG 3-conductor stranded cable
Tinned copper for enhanced conductivity
Polyolefin insulation for durability
Foil or copper tape shielding
LSZH / FRNC jacket for safety
300V voltage rating
500m reel for extended use

Specifications

American Wire Gauge	20AWG
Cable Length	500m
Cable Type	Electronic Cable
Device Supported	Computer
Impedance	69Ohm
Jacket Type	Halogen-Free Jacket
Limited Warranty	10-Year
Material	LSZH; Polyethylene; Tinned Copper
Number of Conductors	3
Package Type	Reel/Spool
Product Series	Data Cables
Product Type	Multi-Pair Cable
Shielding	Yes
Solid or Stranded	Stranded
Colour	Blue
Manufacturer	Belden CDT, Inc
RoHS Compliant	Compliant
WEEE Compliant	Compliant
