The C-TEC PDA5/SW is a wall-mounting 4.75A hearing loop amplifier from C-TEC's PDA/S range, for hearing (induction) loop systems in areas up to 200m².
Key features
- Suitable for areas up to 200m²
- Intuitive LED interface for simple set-up of input levels, output current, phantom power and metal compensation
- 1 XLR mic input (with switchable 12V phantom power), 1 XLR line input and 1 outreach connector
- Class D output stage for maximum efficiency
- Audio processing designed for clear speech and music reproduction
- Dual action automatic gain control compensates for poor microphone technique
- Fault relay and LED indicators show operating and fault status
- Line level output for recording or daisy-chaining multiple units to cover larger areas
- Complies with EN62368-1
Technical specifications
-
Order code: PDA5/SW
-
Type: Wall-mounting (requires a permanent 5A fused spur connection to mains)
-
Coverage: 200m² approx.
-
Mains supply: 230V 50Hz
-
Output: 4.75A loop drive current @ 1 Ohm; loop output voltage 14V
-
Inputs: 1 x XLR mic input with switchable 12V phantom power, 1 x XLR line input, 1 x outreach connector
-
Indicators: LED display with level, peak and limit indicators; Mic, 12V, Line, Metal, Outreach, Lock, Loop, Fault, Hot and Power indicators
-
Controls: Line input, microphone, 12V phantom, outreach, metal compensation, loop drive
-
Connections: Mic (3-way pluggable), line in, loop (4-way), outreach (4-way pluggable), line out (3-way pluggable), fault relay (3-way pluggable)
-
Dimensions: 298 H x 308 W x 74 D mm
-
Weight: 3.35kg
-
Construction: 1mm mild steel zintec, black powder coated
-
IP rating: IP40
-
Operating conditions: -5ºC to +40ºC, max. 95% relative humidity
