The C-TEC CP414BTV is a CAST-PRO multi-function device in a black housing. It combines a smoke and heat multisensor detector, a 92dB(A) tone sounder and a C-3-9.4 white visual alarm device (VAD) in one unit at a single address. It is designed for C-TEC’s XFP and ZFP CAST protocol addressable fire panels and fits the CA408 CAST base (base not included).
Key features
- Smoke & heat multisensor detection, tone sounder and white VAD in a single black device
- MASC™ (Miniature Advanced Smoke Detection Chamber) and AFFIRM™ algorithms for high tolerance to false alarms
- Drift compensation
- Onboard short-circuit loop isolator
- Two 8mm x 2mm ultra-bright red LED indicating strips giving 360° visibility, plus optional remote LED
- 8 detection modes, with different sensitivities selectable for different times of the day
- Fits the CA408 CAST base with integrated locking mechanism and ID tag (CA408R relay base also available)
Technical specifications
- Protocol: C-TEC CAST (XFP/ZFP CAST panels)
- Type: heat & smoke detection plus tone alarm and white VAD
- Detection modes: 8 (default mode 7)
- Supply wiring: 2-wire, polarity sensitive
- Operating voltage: 28 to 40V DC
- Quiescent current: 590µA at 40V
- Alarm current: 13.2mA max. / 10.8mA average (max. volume, VAD lit)
- Sound output: 92dB(A) at 1m
- VAD: C-3-9.4 (10m²/mA efficiency; 0.5Hz synchronised)
- Dimensions: 105mm diameter x 51mm deep (detector only); 105mm x 68mm deep in base
- Weight: 130g (not in base); 185g (in base)
- IP rating: IP21C
- Operating conditions: -10°C to +50°C, max. 95% RH (non-condensing)
- Approvals: EN54-3, 5, 7, 17, 23 & 29 by Kiwa Telefication; EN54-13 by Kiwa Telefication & DBI; CPR number 0063-CPR-242190011
