C-TEC CFP 2 Zone Conventional Fire Panel Replacement Motherboard (CFP702-4M)

The C-TEC CFP702-4M is a replacement motherboard (main PCB) for the C-TEC CFP702-4 standard two zone conventional fire alarm panel. The CFP702-4 is certified to EN54 parts 2, 4 and 13 and works with C-TEC's ActiV conventional fire detectors, sounders and visual alarm devices. Use this board to repair an existing CFP702-4 panel.

Key features

• For the CFP702-4 two zone conventional panel
• Two detector zone circuits and four conventional sounder circuits
• Engineering functions including zone test, coincidence (double knock), zone delays, non-latching zones and one-man walk test
• Two on-board relays (Fire and Fault)
• Two open-collector outputs (Remote and Reset)
• Class change and alert inputs
• Combined keypad/keyswitch entry with colour-coded buttons
• Expansion connections for a CFP761 network card (up to eight two-wire repeaters), CFP relay output cards and EN54-13 sounder circuit interface boards

Technical specifications

• Detector zones: 2 (max 500m per circuit)
• Max devices per zone: 25 detectors (or 32 detectors/manual call points combined)
• Call point resistor: 470 to 680Ω
• Conventional sounder circuits: 4 (max 500m per circuit)
• Max sounder output current: 4 x 200mA (800mA total)
• EOL resistor: 6800Ω
• Alarm voltage: 27V max, 20V min
• Relays: Aux Fire and Fault, volt-free single pole changeover, max 1A at 30V DC
• Open-collector outputs: Reset and Remote, max sink current 30mA
• Inputs: Class Change and Alert (connect to 0V to trigger, max 27V)
• Auxiliary output: 24V, protected by a resettable fuse
