C-TEC CFP AlarmSense 4 Zone 2-Wire Fire Alarm Panel (CFP704-2)

The C-TEC CFP AlarmSense 4 Zone Two-Wire Fire Alarm Panel (CFP704-2) is an LPCB certified EN 54-2/4 control panel designed to work with Apollo's AlarmSense range. By using different voltage bands for quiescent and alarm states, AlarmSense detectors, call points, sounders and visual indicators can all be connected to the same pair of wires on each zone.

Key features

• Designed for Apollo AlarmSense detectors, call points, sounders and visual indicators: detection and alarm devices share the same pair of wires, giving around a 20-25% labour saving over a standard four-wire system
• Four additional conventional sounder circuits
• Integral 1.5A EN 54-4/A2 compliant switch mode PSU
• Engineering functions including zone test, coincidence (double knock), zone delays, non-latching zones and one-man walk test
• Fire and fault relays (volt-free changeover, 1A 30V DC) and two open-collector outputs (remote and reset)
• Class change and alert inputs
• Colour-coded buttons with combined keypad/keyswitch entry
• Flush or surface mountable plastic enclosure, no bezel required
• Expansion for up to eight repeaters (one CFP761 network card per system), relay output cards and EN 54-13 sounder circuit boards
• Manufactured in the UK by C-TEC

Technical specifications

• Part number: CFP704-2
• AlarmSense zones: 4 (max. 500m per circuit)
• Conventional sounder circuits: 4
• Mains supply: 230V 50/60Hz, 350mA max
• Internal power supply: 19-28.5V (27V nominal)
• Quiescent current: 25mA
• Batteries: 2 x 12V 3.2Ah VRLA (in series)
• Approvals: EN 54-2/4, LPCB certified
