C-TEC CFP 4 Zone Conventional Fire Alarm Panel (CFP704-4)

The C-TEC CFP704-4 is a 4 zone conventional fire alarm control panel from the CFP Standard range, certified to EN54 parts 2, 4 and 13. It is housed in a flush or surface mountable plastic enclosure and is fully compatible with C-TEC's ActiV conventional fire detectors, sounders and visual alarm devices.

Key features

• Third-party certified to EN54-2 and EN54-4 by the LPCB and to EN54-13 by Kiwa Telefication
• Four detector zone circuits and four conventional sounder circuits
• Integral 1.5A EN54-4/A2 compliant switch mode power supply
• Engineering functions including zone test, coincidence (double knock), zone delays and non-latching zones
• Two on-board relays (Fire and Fault) and two open-collector outputs (Remote and Reset)
• Class change and alert inputs
• Colour-coded buttons with combined keypad/keyswitch entry
• Expansion connections for up to eight two-wire repeaters (one CFP761 network card required per system), optional CFP relay boards and EN54-13 sounder circuit boards
• Flush or surface mounting with no bezel required
• Manufactured by C-TEC in the UK

Technical specifications

• Order code: CFP704-4
• Mains supply: 230V 50/60Hz, 350mA maximum
• Internal power supply: 19V to 28.5V (27V nominal)
• Total output current: limited to 1.5A @ 230V AC
• Quiescent current: 25mA
• Batteries: 2 x 12V 3.2Ah VRLA in series (minimum 1.2Ah)
• Detector zones: 4 (maximum 500m per circuit); up to 25 detectors, or 32 detectors and manual call points combined, per zone
• Call point resistor value: 470 to 680Ω
• Sounder circuits: 4 (maximum 500m per circuit); 4 x 200mA (800mA total)
• End-of-line resistor: 6800Ω
• Auxiliary relays: 2 x volt-free single pole changeover (Fire, Fault), rated 1A at 30V DC
• Auxiliary output: 24V aux. power, protected by a resettable fuse
• Dimensions: 380 W x 235 H x 96 D mm (flush mounting hole 367 W x 220 H x 75 D mm)
• Construction: plastic lid and base, RAL7035 textured
• IP rating: IP30
• Weight: 1.75kg (without batteries)
• Operating temperature: -5°C to +40°C, maximum 95% relative humidity
