The Controlsoft AC-3214 is the slim mullion-style 125kHz proximity reader head for the Controlsoft Solo standalone single-door access control unit. It is the reader supplied with the Solo Mullion kit (AC-3210). It can also be bought separately as a replacement, or as a second reader so the Solo controller can read on both entry and exit.
The Solo system is a cost-effective single-door access control solution for up to 999 users. It is programmed with a master card and reads Controlsoft 125kHz cards and tags such as the AC-7101 keyfob.
Key features
- Reader head for the Controlsoft Solo standalone controller
- Housing rated to IP68, suitable for indoor or outdoor use
- Bi-colour LED and buzzer for user feedback
- Reads Controlsoft 125kHz proximity cards and tags
- Can be used as a second reader for in/out operation
Technical specifications
- Part number: AC-3214
- Frequency: 125kHz
- Reader head housing: IP68
- Reader head dimensions: 119 x 42 x 22mm
- Compatible controller: Controlsoft Solo (AC-3210 / AC-3210-V)
- Compatible credentials: AC-7080 clamshell card, AC-7100 ISO card, AC-7101 keyfob, AC-7102 thin keyfob, AC-7103 sticker tag, AC-7130 ISO magstripe and prox card
- Solo system operating temperature: -20°C to +60°C
- Solo system operating humidity: 0 to 95% non-condensing
