The Edwards 4-LCDAUDTELCAB-CB is an audio/telephone LCD module kit for lobby cabinets on the Edwards EST4 life safety control platform. It is a 4-LCDAUDTEL display with cable, supplied with a 4-BRKT-CB bracket for mounting in 3-CAB7B, 3-CAB14B and 3-CAB21B series cabinets.
The LCD module provides a dedicated colour touch-screen interface for selecting page circuits and for placing and receiving calls over the firefighters' telephone handset. It has no common control buttons, and can be the only means of audio and telephone selection or be used together with LED-switch modules.
Key features
- Colour touch screen for page circuit selection
- Places and receives firefighter telephone calls
- Can be used alone or with EST4 LED-switch modules
- Takes two spaces on the UI frame assembly
- Supplied with 4-BRKT-CB bracket, which mounts on the back plane of a 3-CHAS7 chassis
Technical specifications
- Model: 4-LCDAUDTELCAB-CB
- Compatible cabinets: 3-CAB7B, 3-CAB14B, 3-CAB21B series
- Display: 18-bit colour, 640 × 480 pixels, resistive touch screen
- Current (connected to 4-ANNCPU): 93 mA active; 40 mA standby at 20% brightness
- Operating temperature: 0 to 49°C
- Relative humidity: 0 to 93% non-condensing
- Shipping weight: 1.32 kg
- System: EST4
- Data sheet reference: E85014-0002
What's in the box
- 1 × LCD module for audio/telephone control, with cable
- 1 × 4-BRKT-CB mounting bracket
