| Product Dimensions (W × H × D) |
90.8 mm × 187.87 mm × 57.87 mm (3.58'' × 7.4'' × 2.28'') |
| Package Dimensions (W × H × D) |
132 mm × 228 mm × 91 mm (5.19" × 8.97" × 3.58") |
| Net Weight |
0.307 kg (0.677 lb) |
| Gross Weight |
0.807 kg (1.779 lb) |
| Packing List |
Wireless Bridge × 1, Power Adapter (12 VDC, 1 A) × 1, Binding Tape × 2,10/100/1000 Mbps PoE Injector × 1, Quick Start Guide ×1, Regulatory Compliance and Safety Information × 1 |
| Packing Method |
Single unit packing |
| Working Temperature |
-30 °C to 70 °C (-22 °F to 158 °F) |
| Working Humidity |
5% to 95% (no condensation) |
| Storage Temperature |
-40 °C to 85 °C (-40 °F to 185 °F) |
| Storage Humidity |
5% to 95% (no condensation) |
| Installation Mode |
Pole Mounting |
| Ingress Protection |
IP55 |
| Power Consumption |
2.65 W for typical (1-ch 2MP IPC), Max. 4.5 W |
| Max. Transmission Rate of Air Interface |
≤ 867 Mbps |
| Wireless Standard |
IEEE 802.11/a/n/ac |
| Working Frequency Band |
5150 MHz ~ 5250 MHz,5250 MHz~ 5350 MHz,5470 MHz~ 5725 MHz,5725 MHz~ 5850 MHz,(Note: Available channel may vary with local regulations.) |
| Antenna Gain |
12 dBi |
| Antenna Angle |
(H) Beamwidth [3 dB] 35°, (V) Beamwidth [3 dB] 35° |
| Transmitting Power |
22 dBm @11ac MCS0 (Note: Transmitting power may vary with local regulations.) |
| Receiving Sensitivity |
-84±2dBm@AC80-MCS0 |
| Throughput Rate |
PTP: 230 Mbps/0.5 KM(AC80),200 Mbps/1 KM(AC80),40 Mbps/5 KM(AC80), PTMP(1 to 8): 80 Mbps/1 KM(AC80) |
| Network Interface |
2 × 1000 Mbps RJ45 ports |
| LED Indicator |
Power indicator, LAN indicator, Signal intensity indicator |
| Reset |
Hardware resetting button |
| Power Supply |
12 VDC/1 A Passive PoE |
| Application Function |
TDMA, DFS, TPC, IFM, IPM |
| Channel Width |
20/40/80 MHz |
| Channel Selection |
Auto/manual selection |
| Security Mode |
WPA2-PSK |
| Security Mechanism |
Wireless network name hidden |
| Network Protocol |
NTP (network time synchronization), SADP (auto search for IP address), HTTPS/HTTP (web management), SSH (debugging) |
| Management Method |
Web, iVMS-4200, HCP, HPP |
| System Log |
Syslog, Control center information |
| Upgrade |
Web, iVMS-4200, HCP, HPP |
| HPP |
Support one-click activation and remote management via Hik-Partner Pro. Functions supported: | 1. Reboot device | 2. Restore device | 3. Display the topology information | 4. Display the connection status between AP and CPEs, including signal intensity, background noise, sending & receiving rate | 5. Configure wireless settings, including working mode, SSID, password, channel, channel bandwidth, transmitting power | 6. Bridge alignment | 7. Spectrum scanning |
| EMC |
CE-EMC(EN 55032, EN 55035, EN 61000-3-2, EN IEC 61000-3-2, EN 61000-3-3, EN 50130-4), IC(ICES-003, Issue 7) |
| Safety |
CB (IEC 62368-1), CE-LVD (EN 62368-1) |
| Chemistry |
CE-RoHS (2011/65/EU), WEEE (2012/19/EU), Reach (Regulation (EC) No.1907/2006) |
| Radio |
EN 301 893, EN 300 440, EN 301 489-3, EN 301 489-17, EN 301 489-1, EN IEC 62311 |
