IFSNetworks PS48VDC100W-DIN 48VDC 100W DIN Rail Power Supply

The IFS PS48VDC100W-DIN is a 48V DC, 100W DIN rail power supply from Carrier (KGS Fire & Security). It is a compact supply for powering PoE network switches and media converters in security and CCTV installations.

It accepts a universal 90–264V AC mains input and mounts on a standard DIN rail in an enclosure or cabinet.

Key features

• 48V DC output, 100W
• Universal 90–264V AC input, 47–63Hz
• DIN rail mounting
• For use with PoE switches and media converters
• CE, UL and CSA approved

Technical specifications

• Part number: PS48VDC100W-DIN
• Input: 90 to 264V AC, 47 to 63Hz
• Output: 48V DC, 2A (100W)
• Form factor: DIN rail mount
• Dimensions: 55 x 90 x 100mm
• Weight: 420g
• Colour: white
• Compliance: CE, REACH, RoHS 2, WEEE
• EMC: EN55022 Class B, EN61204-3 Class B, FCC Part 15 Class B, EN55024
